DW-2SD Series

DW-2SD Series

DW-2SD

$12.00

Send Inquiry

Get in touch

Need Help? info@apt-international.com
Monday - Friday 9:00 - 17:00
Product Code Max. A.C Output A.C Frequency Rated Ac Output Rated Voltage Rated Current Engine Total Displacement Fuel Tank Capacity Lube. Oil Capacity Net Weight
DW-2SD10000/3 11.2 kW 50Hz 10 kW 220/380V 45/15A YD385B 1.532L 38L 4.8L 520kg
DW-2SD10000/3-ATS 13.2 kW 60Hz 12 kW 220/380V 54/18A YD385B 1.532L 38L 4.8L 520kg
DW-2SD20000/4 22 kW 50Hz 20 kW 220/380V 90/30A YD490 2.19L 68L 6.9L 750kg
DW-2SD20000/4-ATS 27.2 kW 60Hz 25 kW 220/380V 114/38A YD490 2.19L 68L 6.9L 750kg
DW-2SD30000/4 32.8 kW 50Hz 30 kW 220/380V 136/45A YD4102 2.771 L 95L 8.5L 885kg
DW-2SD30000/4-ATS 38.4 kW 60Hz 35 kW 220/380V 159/53A YD4102 2.771 L 95L 8.5L 885kg
DW-2SD40000/4 44 kW 50Hz 40 kW 220/380V 182/61A LR4B5-D86F-U2 4.33 L 95L 11 L 995kg
DW-2SD40000/4-ATS 49.6 kW 60Hz 45 kW 220/380V 205/68A LR4B5-D86F-U2 4.33 L 95L 11 L 995kg
DW-2SD50000/4 55.2 kW 50Hz 50 kW 220/380V

 227/76A YT4B2Z-D20 6.494 L 95L 18.5L 1050kg
DW-2SD50000/4-ATS 66.4 kW 60Hz 60 kW 220/380V 273/91A YT4B2Z-D20 6.494 L 95L 18.5L 1050kg
